RAM

In most cases, the maximum project size that can be processed on a machine is limited by the amount of RAM available. Therefore, it is important to select a platform that allows the amount of RAM required for the projects to be processed to be installed. See the article Memory Requirements for information on typical RAM consumption in common processing steps.

CPU

GPU

Agisoft Metashape supports GPU acceleration for most resource-intensive processing steps, due to which it is possible to accelerate processing using high-end OpenCL or CUDA-compatible graphics cards with a large number of unified shaders (CUDA cores or shader processing units).

Basic Configuration

up to 32 GB RAM (Laptop or Desktop)

CPU: 4 – 12 cores Intel, AMD or Apple M1/M2 processor, 2.0+ GHz

RAM: 16 – 32 GB

GPU: NVIDIA or AMD GPU with 1024+ unified shaders
(For example: GeForce RTX 2060 or Radeon RX 5600M)

Advanced Configuration

up to 128 GB RAM (Desktop or Workstation)

CPU: 6 – 32 cores Intel or AMD processor, 3.0+ GHz
(For example: Intel i7 / i9 or AMD Ryzen 7 / Ryzen 9 / Threadripper)

RAM: 32 – 128 GB

GPU: 1 – 2 NVIDIA or AMD GPUs with 1920+ unified shaders
(For example: GeForce RTX 3080 or Radeon RX 6800 XT)

Extreme Configuration

128+ GB RAM (Server)

For processing of extremely large data sets a dual-socket Intel Xeon or AMD EPYC based servers (3.0+ GHz) with Quadro, Tesla, Radeon Pro or Instinct GPUs can be used.

Global Geoid Models

Converted from USA NGA data under public domain license.

EGM84 30′ geoid model
WGS 84 (EPSG::4326) to EGM84 height (EPSG::5798)

EGM96 15′ geoid model
WGS 84 (EPSG::4326) to EGM96 height (EPSG::5773), included with Agisoft Metashape

EGM2008 2.5′ geoid model
WGS 84 (EPSG::4326) to EGM2008 height (EPSG::3855)

EGM2008 1′ geoid model
WGS 84 (EPSG::4326) to EGM2008 height (EPSG::3855)

Installation instructions

Geoids are supported in Metashape Professional edition only.

Metashape uses Geodetic TIFF grids (GTG) geoid format starting from version 1.7. For earlier Metashape versions please download geoids from Obsolete Geoids page.

01 /Downloadgeoid file.

02 /Copydownloaded file into geoids folder in Metashape Professional installation directory.

03 /RestartAgisoft Metashape Professional.

Argentina

Converted from IGN data.

SRVN16 geoid model
POSGAR 2007 (EPSG::5340) to SRVN16 height (EPSG::9255)

Australia

Converted from Geoscience Australia data under Creative Commons Attribution 4.0 license.

AUSGeoid93 geoid model
AGD84 (EPSG::4203) to AHD height (EPSG::5711)

AUSGeoid98 geoid model
AGD84 (EPSG::4203) to AHD height (EPSG::5711)

AUSGeoid09 geoid model
GDA94 (EPSG::4283) to AHD height (EPSG::5711)

AUSGeoid20 geoid model
GDA2020 (EPSG::7844) to AHD height (EPSG::5711)

Canada

Converted from Natural Resources Canada data copyright Her Majesty the Queen in right of Canada.

CGVD2013 geoid model, NAD83(CSRS) version
NAD83(CSRS) (EPSG::4617) to CGVD2013(CGG2013) height (EPSG::6647)

CGVD2013 geoid model, ITRF version
ITRF2008 (EPSG::8999) to CGVD2013(CGG2013) height (EPSG::6647)

CGVD28 geoid model
NAD83(CSRS) (EPSG::4617) to CGVD28 height (EPSG::5713)

CGG2010 geoid model
NAD83(CSRS) (EPSG::4617) to CGG2010

CGG2005 geoid model
NAD83(CSRS) (EPSG::4617) to CGG2005

CGG2000 geoid model
NAD83(CSRS) (EPSG::4617) to CGG2000

GSD95 geoid model
NAD83(CSRS) (EPSG::4617) to GSD95

GSD91 geoid model
NAD83(CSRS) (EPSG::4617) to GSD91

Denmark

Converted from Agency for Data Supply and Efficiency data under Creative Commons Attribution 4.0 license.

DVR90 geoid model
ETRS89 (EPSG::4258) to DVR90 height (EPSG::5799)

Finland

Converted from National Land Survey of Finland data under Creative Commons Attribution 4.0 license.

N2000 geoid model
ETRS89 (EPSG::4258) to N2000 height (EPSG::3900)

N60 geoid model
ETRS89 (EPSG::4258) to N60 height (EPSG::5717)

France

Converted from IGN data under Open License license.

RAF09 geoid model
RGF93 v1 (EPSG::4171) to NGF-IGN69 height (EPSG::5720)

RAF20 geoid model
RGF93 v2b (EPSG::9782) to NGF-IGN69 height (EPSG::5720)

RAC09 geoid model
RGF93 v1 (EPSG::4171) to NGF-IGN78 height (EPSG::5721)

RAC23 geoid model
RGF93 v2b (EPSG::9782) to NGF-IGN78 height (EPSG::5721)

Germany

Converted from BKG data under Creative Commons Attribution 4.0 license.

GCG2011 geoid model
ETRS89 (EPSG::4258) to DHHN92 height (EPSG::5783)

GCG2016 geoid model
ETRS89 (EPSG::4258) to DHHN2016 height (EPSG::7837)

GCG2016/2023 geoid model
ETRS89 (EPSG::4258) to DHHN2016 height (EPSG::7837)

Japan

Converted from Geospatial Information Authority of Japan data under Creative Commons Attribution 4.0 license.

GSIGEO2011 geoid model
JGD2000 (EPSG::4612) to GSIGEO2011

Mexico

Converted from INEGI data under Creative Commons Attribution 4.0 license.

GGM2010 geoid model
WGS 84 (EPSG::4326) to Geoid Gravimetrico Mexicano 2010

Netherlands

Converted from NSGI data under Creative Commons Attribution 4.0 license.

NLGEO2004 geoid model
ETRS89 (EPSG::4258) to NAP height (EPSG::5709)

NLGEO2018 geoid model
ETRS89 (EPSG::4258) to NAP height (EPSG::5709)

New Zealand

Converted from Land Information New Zealand data under Creative Commons Attribution 4.0 license.

NZVD2009 geoid model
NZGD2000 (EPSG::4167) to NZVD2009 height (EPSG::4440)

NZVD2016 geoid model
NZGD2000 (EPSG::4167) to NZVD2016 height (EPSG::7839)

Norway

Converted from Kartverket data under Creative Commons Attribution 4.0 license.

NN 54 geoid model
ETRS89 (EPSG::4258) to NN54 height (EPSG::5776)

NN 2000 (2018A) geoid model
ETRS89 (EPSG::4258) to NN2000 height (EPSG::5941)

NN 2000 (2018B) geoid model
ETRS89 (EPSG::4258) to NN2000 height (EPSG::5941)

Papua New Guinea

Converted from ASPNG data.

PNG08 geoid model
WGS 84 (EPSG::4326) to PNG08

Portugal

Converted from DG Territory data under Creative Commons Attribution 4.0 license.

GeodPT08 geoid model
ETRS89 (EPSG::4258) to GeodPT08

Slovenia

Converted from Geodetska uprava Republike Slovenije data.

SLO_AMG2000 geoid model
Slovenia 1996 (EPSG::4765) to SVS2000 height (EPSG::5779)

SLO_VRP2016 geoid model
Slovenia 1996 (EPSG::4765) to SVS2010 height (EPSG::8690)

South Africa

Converted from CDNGI data under Creative Commons Attribution 4.0 license.

SAGEOID10 geoid model
ITRF2005 (EPSG::8998) to SA LLD height (EPSG::9279)

Spain

Converted from IGN data under Creative Commons Attribution 4.0 license.

EGM08-REDNAP geoid model
ETRS89 (EPSG::4258) to Alicante height (EPSG::5782)

EGM08-REDNAP Canarias geoid model
REGCAN95 (EPSG::4081) to Gran Canaria height (EPSG::9397)

Sweden

Converted from Lantmäteriet data under Creative Commons CC0 1.0 license.

SWEN08_RH70 geoid model
SWEREF99 (EPSG::4619) to RH70 height (EPSG::5718)

SWEN08_RH2000 geoid model
SWEREF99 (EPSG::4619) to RH2000 height (EPSG::5613)

SWEN17_RH70 geoid model
SWEREF99 (EPSG::4619) to RH70 height (EPSG::5718)

SWEN17_RH2000 geoid model
SWEREF99 (EPSG::4619) to RH2000 height (EPSG::5613)

Switzerland

Converted from Swisstopo data under Creative Commons CC0 1.0 license.

CHGeo2004 geoid model
ETRS89 (EPSG::4258) to LHN95 height (EPSG::5729)

CHGeo2004 geoid model
ETRS89 (EPSG::4258) to LN02 height (EPSG::5728)

United Kingdom

Converted from Ordnance Survey data under The 2-Clause BSD License license.

OSGM02 geoid model (EPSG::5101)

OSGM15 geoid model (EPSG::5101)

United States

Converted from USA NOAA data under public domain license.

Geoid 99
NAD83 (EPSG::4269) to NAVD88 height (EPSG::5703)

Geoid 03
NAD83 (EPSG::4269) to NAVD88 height (EPSG::5703)

Geoid 06
NAD83 (EPSG::4269) to NAVD88 height (EPSG::5703)

Geoid 09, Conterminous United States
NAD83 (EPSG::4269) to NAVD88 height (EPSG::5703)

Geoid 09, Guam and Northern Mariana Islands
NAD83 (EPSG::4269) to GUVD04 height (EPSG::6644)

Geoid 09, Puerto Rico and U.S. Virgin Islands
NAD83 (EPSG::4269) to PRVD02 height (EPSG::6641)

Geoid 09, American Samoa
NAD83 (EPSG::4269) to ASVD02 height (EPSG::6643)

Geoid 12A, Conterminous United States
NAD83(2011) (EPSG::6318) to NAVD88 height (EPSG::5703)

Geoid 12A, Guam and Northern Mariana Islands
NAD83(PA11) (EPSG::6322) to GUVD04 height (EPSG::6644)

Geoid 12A, Hawaii
NAD83(PA11) (EPSG::6322) to NAVD88 height (EPSG::5703)

Geoid 12A, Puerto Rico and U.S. Virgin Islands
NAD83(2011) (EPSG::6318) to PRVD02 height (EPSG::6641)

Geoid 12A, American Samoa
NAD83(PA11) (EPSG::6322) to ASVD02 height (EPSG::6643)

Geoid 12B, Conterminous United States
NAD83(2011) (EPSG::6318) to NAVD88 height (EPSG::5703)

Geoid 12B, Guam and Northern Mariana Islands
NAD83(PA11) (EPSG::6322) to GUVD04 height (EPSG::6644)

Geoid 12B, Hawaii
NAD83(PA11) (EPSG::6322) to NAVD88 height (EPSG::5703)

Geoid 12B, Puerto Rico and U.S. Virgin Islands
NAD83(2011) (EPSG::6318) to PRVD02 height (EPSG::6641)

Geoid 12B, American Samoa
NAD83(PA11) (EPSG::6322) to ASVD02 height (EPSG::6643)

Geoid 18, Conterminous United States
NAD83(2011) (EPSG::6318) to NAVD88 height (EPSG::5703)

Geoid 18, Puerto Rico and U.S. Virgin Islands
NAD83(2011) (EPSG::6318) to PRVD02 height (EPSG::6641)
